Driver Monitoring System (DMS) Camera
The CTL-DMS-S2 is a high-performance DMS camera featuring an SOI H65 CMOS sensor with Full HD-720P resolution. It offers a wide 85° diagonal viewing angle, 2D noise reduction, and wide dynamic range (WDR) for clear image capture in various lighting conditions. With a 3.6mm focal length, it operates efficiently in temperatures ranging from -25°C to 75°C and supports a 12V DC power input. Ideal for driver monitoring systems, it ensures reliable performance with a 2.5m cable and low power consumption.
📦 Package Includes:
- ✓ -Channel MDVR Unit
Specifications
Description
Technical Specifications
Specifications | Model | CTL-DSM-E1-MIC |
Type | DMS Camera | |
Sensor Type | 200W CMOS Sensor | |
Original Size | 2.9μm x2.9 μm | |
Lens | 1/2.7" | |
Focal Length | 6mm | |
Aperture | F1.8 | |
FOV | D=60° H=49° V=35° | |
Image Mode | Black & White | |
Resolution | 1280*1080P | |
Dynamic Range | 80dB | |
Signal to Noise Ratio | 39dB | |
Synchronization | NA | |
LED | 940nm/0.45W | |
Illuminance | Minimum≤0.01Lux | |
Audio | Support | |
Video | AHD | |
Video format | PAL(Default) | |
Frame Rate | 25fps | |
Electronic Shutter | AUTO | |
AGC | AUTO | |
White Balance | Support | |
Backlight Compensation | AUTO | |
Waterproof Level | NA | |
Humidity | ≤ 90 % | |
Characteristic | Voltage | 12V DC |
Consumption | 1.32W | |
Length of Tail | 3.5m | |
Temperature Range | -25℃~75℃ |
